POFI ProductionChuck 210 ER-032964

POFI ProductionChuck 210, the same as ER-032964.
1.Version: Chuck for high machining forces in chip cutting. Low design. Through-borehole ø 81 mm.
2.Application:On milling machines, lathes and grinding machines. To clamp pallets PC 210.
3.Connections:2 air connections: on the sides and from below through customized base plate.
4.Operation: With air gun or control unit.
5.Repeatability:0.002 mm
6.Indexation of pallet:4 x 90°
7.clamped without pressure: 20'000 N
8.Max. rotating speed:4'500 min
Availability:
sharethis sharing button

POFI ProductionChuck 210, the same as ER-032964.

1.Version: Chuck for high machining forces in chip cutting. Low design. Through-borehole ø 81 mm.

2.Application:On milling machines, lathes and grinding machines. To clamp pallets PC 210.

3.Connections:2 air connections: on the sides and from below through customized base plate.

4.Operation: With air gun or control unit.

5.Repeatability:0.002 mm

6.Indexation of pallet:4 x 90°

7.clamped without pressure: 20'000 N

8.Max. rotating speed:4'500 min

Made in China POFI ProductionChuck 210 ER-032964ER-032964 ProductionChuck 210ER-032964 ProductionChuck 210 pofiPOFI ER-032964 ProductionChuck 210
