POFI WGS Gripper 500 Module for End of Robot Arm

9

POFI WGS Gripper 500 Module for End of Robot Arm

Name: POFI WGS Gripper 500 Module for End of Robot Arm
Brand: POFI
Rating: 5.0 (37 reviews)

POFI WGS Gripper 500 module is a end tooling for robot arm. It applies to coupling with MTS, UPC pallets or any other devices which are equipped with gripper link 500. It is a complement to existing RCS5 handling system. The maximum torque is able to reach to 2000Nm. The maximum transfer weight with turbo is up to 500kgs. Coupling kit including dowel pin (2x) φ10x20. 4 air lines integrated. Elbow union air connection joint (6x) φ6. 4 of them are for air transfer through gripper link to the end devices or tools control, the other 1 is for opened and closed, the last 1 is for air pressurization (Turbo). The default signal transfer kit 10Ma-10Pins is integrated, external transfer signal transfer cable is included also.


Availability:



Inquire

Model:
PO-MD102
Brand:
POFI

Product Description

POFI WGS Gripper 500 Module for End of Robot Arm

Product Name: POFI WGS Gripper 500 Module for End of Robot Arm

Item No.: PO-MD102

Description: POFI WGS Gripper 500 module is a end tooling for robot arm. It applies to coupling with MTS, UPC pallets or any other devices which are equipped with gripper link 500. It is a complement to existing RCS5 handling system. The maximum torque is able to reach to 2000Nm. The maximum transfer weight with turbo is up to 500kgs. Coupling kit including dowel pin (2x) φ10x20. 4 air lines integrated. Elbow union air connection joint (6x) φ6. 4 of them are for air transfer through gripper link to the end devices or tools control, the other 1 is for opened and closed, the last 1 is for air pressurization (Turbo). The default signal transfer kit 10Ma-10Pins is integrated, external transfer signal transfer cable is included also.
