Fixture Selection for Different Material Electrodes

                                                             Fixture Selection for Different Material Electrodes

A:Graphite Electrode Fixture Selection

‌1.Recommended EROWA Fixture‌: Specifically designed for EDM, ensuring precise positioning of the electrode relative to the machine tool and minimizing processing deviations

‌2.Material Compatibility‌: Optimized design tailored to the characteristics of graphite electrodes, balancing conductivity and clamping functionality

3‌.Complex Shape Processing: Supports processing of irregularly shaped electrodes, addressing issues with traditional fixtures that are difficult to form

4.Vacuum Suction Fixtures: For thin plates and other shapes, prevents bending and distortion, facilitating dimensional accuracy

Copper Electrode Fixture Selection

‌B: Specialized Copper Electrode Fixture Mounts: Such as POFI copper electrode fixture mounts, a set of 12, each containing 2 fixing screws, made of copper

1‌.EROWA fixtures: Can also be used for copper electrodes, but the weight of the copper electrodes must be considered

2.Quick-positioning precision fixtures: Compared to traditional vise clamps (3 minutes per piece) and manual fixtures (1 minute per piece), they can achieve 10-second clamping, reducing human errors

3‌.Stainless steel clamping heads: Such as the EROWA electrode clamping head U-shaped stainless steel copper electrode fixture, available in multiple specifications

We design tools to sit more working conditions and compatible with other famous brand, like EROWA and System 3R. We cooperate their advantages to improve our designing to suit moe conditions and make tools easy to operate. While save cost for customers.

Feel free contact to us if you have needs.
